360° Ceiling Surface Mount Passive Infrared (PIR) Motion Sensor

$19.00 On Sale

1 review

This 360° Ceiling Surface Mounted motion sensor detects motion in a room with a full field of view in all directions. Designed to be mounted in the center of a room, the motion sensor connects to a standard 4-core alarm wire and is powered by 12VDC from the AUX output of your Konnected Alarm Panel.


  • Detects motion in all directions, up to 25ft (8m) away
  • 120 ° field of view facing downward from the ceiling
  • Designed for 8ft~10ft (2.5m~3m) ceilings.
  • LED indicator illuminates when motion is detected (can be disabled).
  • Dry contact output can be set as Normally Open (NO) or Normally Closed (NC). Factory setting is Normally Closed.
  • Very low power consumption.
  • Small, inconspicuous design.
  • Easy to hook-up and mount.


Input power: 12VDC
Output Type: Dry Contact or 12V Output
Dry Contact Output Type: Normally Closed (NC) or Normally Open (NO) Form B
Indicator LED: Yes, configurable.
Country of Origin: China
