12V to 5V USB Power Converter

12V to 5V USB Power Converter

64 reviews

Regular price $12.80
Regular price $16.00 Sale price $12.80
SALE! Sold out
Shipping calculated at checkout.
Connector
OR

This device converts 12V DC power from your system into a 5V USB connection. Use it to install a tablet charger in place of your old keypads! There are 4 variations to choose from.

NOTE: This product comes in four different connector variations. Choose the desired connector from the drop-down above.

Specifications:

Recommended input voltage: 12V
Input voltage range: 8V - 23V DC
Output voltage: 5V DC
Output current: 3A max
Output power: 15W max
Conversion efficiency: >90%
Voltage regulation: ±1%
Load regulation: ±2%
Ripple (full load test): <100mV
No-load current: <15mA
Operating temperature: -25~65℃ [1]
Waterproof rating: IP68
Short-circuit protection: Yes
Overheat protection: Yes
Reverse Polarity Protection: Yes
Case Material: ABS Plastic
Product dimensions: 46mm x 27mm x 14mm
Input (red/black) cable length: ~12cm
Output (USB) cable length: ~35cm
Mounting hole pitch: 52mm
Product weight: 65g
Country of origin: China

[1] Output power is reduced when the ambient temperature exceeds 40℃

View full details
Customer Reviews
4.6 Based on 64 Reviews
5 ★
78%
50
4 ★
13%
8
3 ★
2%
1
2 ★
3%
2
1 ★
4%
3
Customer Photos
Write a Review Ask a Question

Thank you for submitting a review!

Your input is very much appreciated. Share it with your friends so they can enjoy it too!

Filter Reviews:
  • tablet
  • converter
  • Works
  • power
  • wall
  • Shipping
  • system
  • everything
  • install
  • adapter
RH
13 Jun 2024
Robert H.
United States

Tablet power

Making the usb c thinner and on a 90 angle would be better

IB
12 Dec 2023
Isaac B.
United States United States

Powered dash cam

The USB plug was wrong for my Nextbase dashcam, but I cut and soldered the proper plug onto the adapter with no problem. Works as intended for my 2021 Toyota Highlander Hybrid. The adapter unit and wiring all fit under the rear view mirror housing where I tapped into 12 volts using my voltmeter. I now have a clean installation with no dangling wires running to the lighter socket. My only complaint would be there should be clear pictures of the available power plugs on the adapter description to avoid confusion when ordering .

RG
25 Nov 2023
Robert G.
United States United States

12V to 5V USB Power Converter

Works great. Keeps tablet charged perfectly.

MH
24 Nov 2023
Mitchel H.
United States United States

Works As Advertised

Four. Stars because the finish could be a little better.. with that said, it does what it should do and holds the tablet in place perfectly. Pictures attached..

Konnected 12V to 5V USB Power Converter ReviewKonnected 12V to 5V USB Power Converter ReviewKonnected 12V to 5V USB Power Converter Review
DK
23 Aug 2023
David K.
United States United States

This 12V to 5V USB Power Converter worked perfect!

I used this Konnected 12V to 5V USB power converter to power an iPort Surface Mount iPad station, as iPort no longer makes their converter. With an existing 12V transformer (located remotely) powering a 2-wire connection at the iPad station I added this converter, along with a standard USB to lightning iPad charging cable (using the female USB connection on the Konnected converter kit) and viola! My iPad stays charged. Its about as compact as the old iPort converter and fit inside the single gang electrical workbox. Does what I need and at 1/4 the price of the now disco'd iPort converter. Thanks Konnected!

MK
09 Mar 2023
Michael K.
United States United States

Great Converter

Great converter. I was able to replace my alarm control panel with an Amazon Fire tablet and power it with this converter. Quick and easy installation.

MS
09 Feb 2023
Michael S.
United States United States

The 12V to 5V USB Power Converter works well

Overall, the install was simple. I traced the old control panel cables back to the panel and wired in the 12v system in. The converter installed easily and works just fine with my TabA 9.7.

TA
27 Jan 2023
Terry A.
United States United States

Great Power Supply

This works great. I mounted it to the stud with 2 screws and then connected it to the wires coming from the main board. My Fire Tablet has continuous power now. I highly recommend this for your display and power

Konnected 12V to 5V USB Power Converter Review
DN
09 Jan 2023
Dr.Yvette Nadeau
United States United States

Superb system

The two Konnected Pro devices plus the accessories to power a few fireOS devices are amazing. Many possibilities using SharpTools through numerous platforms to choose from to fully customize a home automation system.

BC
04 Jan 2023
Brendan C.
Ireland Ireland

12V to 5V USB Power Converter

Excellent product. Have connected my old tablet to it. Now just need to get it working

A Konnected Customer
DO
02 Nov 2022
DAVID O.
United States United States

Worked like a charm!

Easy install, good instructions, very compact. I would suggest offering a lightning cable option, but was not a show stopper! I replaced my old ADT panel with an iPad Mini

BH
11 Aug 2022
Bradley H.
United States United States

Awesome products!

This guy is simple to wire in, I just used my old leads from my old panned Connected them to Konnected aux and I have power to my tablet. Now we just have to get something to work more efficiently on the tablet for the system.

FS
14 Mar 2022
Frank S.
United States United States

USB power converter failed

Customer service was excellent with my issue and quickly sent a replacement without hesitation.

SR
21 Jan 2022
Silviu R.
United States United States

Poor service

Not what I expected

23 Jan 2022

Konnected

If you have a question or issue you can contact us at help@konnected.io

DM
15 Dec 2021
Dennis M.
United States United States

12V to 5V USB Power Converter

The photo I ordered from clearly showed a straight through USB-C connector, but I received a right-angle USB-C connector. I already have a right-angle connector from a previous order, so these two parts are of no use to me because I need a straight through connector.

SS
08 Sep 2021
Scott S.
United States United States

USB-C power converter

Konnected is awesome for alarm automation and self monitoring. The power converter is necessary to charge my new Amazon Fire Tablet that replaced the old alarm panel. Looking forward to working The Tiles features with my Konnected devices. Great support from the Konnected staff.
